Pa lăng điện xích samsung 1 tấn SCO-S1000 / SCO-S1000 Samsung Electric Chain Hoist

Pa lăng điện xích samsung 1 tấn SCO-S1000 / SCO-S1000 Samsung Electric Chain Hoist

Thời gian giao hàng: Vui lòng liên hệ 0988.324.548 / 0906.040.453
Tình trạng: Hàng mới 100%
Giá: liên hệ
Hiệu lực giá bán:
  • Model: SCO-S1000
  • Tải trọng nâng: 1 tấn
  • Tốc độ nâng hạ: 5.8 mét/ phút
  • Công suất motor nâng: 1.25Kw
  • Xích tải: 7.1mm x 1 nhánh
  • Điện áp: 3pha/380V/50Hz
  • Trọng lượng: 60Kg
  • Xuất xứ: Hàn Quốc
  • Nhà sản xuất: SAMSUNG HOIST CO., LTD

Tags:

Pa lăng điện xích samsung 1 tấn SCO-S1000 / SCO-S1000 Samsung Electric Chain Hoist

Pa lăng điện xích samsung 1 tấn SCO-S1000 / SCO-S1000 Samsung Electric Chain Hoist
Powerfull & Safety hoisting are employed to this series, SCO series are based on technology and experience that are accumulated over decades from many improvement to fulfill demand on effective hoisting for material handling equipments.

SCO ELECTRIC HOIST SAMSUNG - 3 PHASE

SCO-S250 ( Single Speed )
Capacity : 250 kg
Hoisting Motor Power : 0.54 kw x 4P
Hoisting Speed : 4.6 m/min
or 7 m/min
Load Chain : Ø 5.0 mm × 1 fall
Net Weight : 36 Kgs
Drawing PDF

SCO-D250 ( Double Speed )
Capacity : 250 kg
Hoisting Motor Power : 0.58 kw x 4P / 0.19 kw x 12P
Hoisting Speed : 4.7/1.6 m/min
or 7/2.3 m/min
Load Chain : Ø 5.0 mm × 1 fall
Net Weight : 36 Kgs
Drawing PDF

SCO-S500 ( Single Speed )
Capacity : 500 kg
Hoisting Motor Power : 0.54 kw x 4P
or 0.92 kw x4P
Hoisting Speed : 4.6 m/min
or 7 m/min
Load Chain : Ø 5.0 mm × 1 fall
Net Weight : 38 Kgs
Drawing PDF

SCO-D500 ( Double Speed )
Capacity : 500 kg
Hoisting Motor Power : 0.58 kw x 4P / 0.19 kw x12P
Hoisting Speed : 4.7/1.6 m/min
Load Chain : Ø 5.0 mm × 1 fall
Net Weight : 38 Kgs
Drawing PDF

SCO-S1000 ( Single Speed )
Capacity : 1000 kg
Hoisting Motor Power : 1.25 kw x 4P
Hoisting Speed : 5.8 m/min
Load Chain : Ø 7.1 mm × 1 fall
Net Weight : 60 Kgs
Drawing PDF

SCO-D1000 ( Double Speed )
Capacity : 1000 kg
Hoisting Motor Power : 1.25 kw x 4P / 0.63 x 8P
Hoisting Speed : 5.8/2.9 m/min
Load Chain : Ø 7.1 mm × 1 fall
Net Weight : 60 Kgs
Drawing PDF

SCO-S1250 ( Single Speed )
Capacity : 1250 kg
Hoisting Motor Power : 1.7 kw x 4P
Hoisting Speed : 5.8 m/min
Load Chain : Ø 7.1 mm × 1 fall
Net Weight : 60 Kgs
Drawing PDF

SCO-D1250 ( Double Speed )
Capacity : 1250 kg
Hoisting Motor Power : 1.7 kw x 4P / 0.85 kw x 8P
Hoisting Speed : 5.8/2.9 m/min
Load Chain : Ø 7.1 mm × 1 fall
Net Weight : 60 Kgs
Drawing PDF

SCO-S1500 ( Single Speed )
Capacity : 1500 kg
Hoisting Motor Power : 2.1 kw x 4P
Hoisting Speed : 6.7 m/min
Load Chain : Ø 8 mm × 1 fall
Net Weight : 65 Kgs
Drawing PDF

SCO-D1500 ( Double Speed )
Capacity : 1500 kg
Hoisting Motor Power : 2.1 kw x 4P / 1.25 kw x 8P
Hoisting Speed : 6.7/3.4 m/min
Load Chain : Ø 8 mm × 1 fall
Net Weight : 65 Kgs
Drawing PDF

SCO-S2000D ( Single Speed )
Capacity : 2000 kg
Hoisting Motor Power : 1.25 kw x 4P
Hoisting Speed : 2.9 m/min
Load Chain : Ø 7.1 mm × 2 fall
Net Weight : 68 Kgs
Drawing PDF

SCO-D2000D ( Double Speed )
Capacity : 2000 kg
Hoisting Motor Power : 1.25 kw x 4P / 0.63 kw x 8P
Hoisting Speed : 2.9/1.5 m/min
Load Chain : Ø 7.1 mm × 2 fall
Net Weight : 68 Kgs
Drawing PDF

SCO-S2500D ( Single Speed )
Capacity : 2500 kg
Hoisting Motor Power : 1.7 kw x 4P
Hoisting Speed : 2.9 m/min
Load Chain : Ø 7.1 mm × 2 fall
Net Weight : 70 Kgs
Drawing PDF

SCO-D2500D ( Double Speed )
Capacity : 2500 kg
Hoisting Motor Power : 1.25 kw x 4P / 0.63 kw x 8P
Hoisting Speed : 2.9/1.5 m/min
Load Chain : Ø 7.1 mm × 2 fall
Net Weight : 70 Kgs
Drawing PDF

SCO-S3000D ( Single Speed )
Capacity : 3000 kg
Hoisting Motor Power : 2.1 kw x 4P
Hoisting Speed : 3.4 m/min
Load Chain : Ø 8 mm × 2 fall
Net Weight : 72 Kgs
Drawing PDF

SCO-D3000D ( Double Speed )
Capacity : 3000 kg
Hoisting Motor Power : 2.1 kw x 4P / 1.25 kw x 8P
Hoisting Speed : 3.4/1.7 m/min
Load Chain : Ø 8 mm × 2 fall
Net Weight : 72 Kgs
Drawing PDF

SCO-S2000 ( Single Speed )
Capacity : 2000 kg
Hoisting Motor Power : 2.9 kw x 4P
Hoisting Speed : 6.8 m/min
Load Chain : Ø 11.2 mm × 1 fall
Net Weight : 110 Kgs
Drawing PDF

SCO-D2000 ( Double Speed )
Capacity : 2000 kg
Hoisting Motor Power : 2.9 kw x 4P / 1.5 kw x 8P
Hoisting Speed : 6.8/3.4 m/min
Load Chain : Ø 11.2 mm × 1 fall
Net Weight : 110 Kgs
Drawing PDF

SCO-S3000 ( Single Speed )
Capacity : 3000 kg
Hoisting Motor Power : 2.9 kw x 4P
Hoisting Speed : 5 m/min
Load Chain : Ø 11.2 mm × 1 fall
Net Weight : 110 Kgs
Drawing PDF

SCO-D3000 ( Double Speed )
Capacity : 3000 kg
Hoisting Motor Power : 2.9 kw x 4P / 1.5 kw x 8P
Hoisting Speed : 5.0/2.5 m/min
Load Chain : Ø 11.2 mm × 1 fall
Net Weight : 110 Kgs
Drawing PDF

SCO-S5000D ( Single Speed )
Capacity : 5000 kg
Hoisting Motor Power : 2.9 kw x 4P
Hoisting Speed : 2.5 m/min
Load Chain : Ø 11.2 mm × 2 fall
Net Weight : 126 Kgs
Drawing PDF

SCO-D5000D ( Double Speed )
Capacity : 5000 kg
Hoisting Motor Power : 2.9 kw x 4P / 1.5 kw x 8P
Hoisting Speed : 2.5/1.3 m/min
Load Chain : Ø 11.2 mm × 2 fall
Net Weight : 126 Kgs
Drawing PDF
